North Bris Digital Routed Number 2


113 replies to this topic

#21 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 24 June 2016 - 06:54 PM

Thanks Grant,

Done a little more progress today with some underside of the track routing for the pit lane changer and first XLC for all the components from the Scalextric track piece to fit into the wooden lane changer. Now that this job is finished i can finish screwing down the board that have been routed and fill all gaps and screw holes and sand back this section ready for paint. This will also allow me to start working on the big banked section up against the back wall that will join onto the front straight

Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image

Obviously i havent cleaned up the furry edges yet but i will do that when i go to install the components.

Cheers John
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#22 Eno the Wonderdog

    Woof Woof and erm.. Bark

  • Auslotters
  • PipPipPipPipPipPipPip
  • 6,885 posts
  • Gender:Male

Posted 24 June 2016 - 07:52 PM

I am SOOO going to have to pick your brains John. I have a plan and it would be WAY cooler in wood than the Plastic Fantastic. I can jiggle angles for a start. Will that be a problem for you?
Captain's log: We are enroute to some planet whose name I cannot pronounce to do something really complicated that I don't understand.

#23 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 24 June 2016 - 08:08 PM

No worries Eno any questions feel free to ask.
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#24 Eno the Wonderdog

    Woof Woof and erm.. Bark

  • Auslotters
  • PipPipPipPipPipPipPip
  • 6,885 posts
  • Gender:Male

Posted 24 June 2016 - 08:31 PM

I've moved west to Bellbird Park so not really that far away - sorta.
Captain's log: We are enroute to some planet whose name I cannot pronounce to do something really complicated that I don't understand.

#25 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 24 June 2016 - 09:37 PM

Ok that is less than an hour away
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#26 Eno the Wonderdog

    Woof Woof and erm.. Bark

  • Auslotters
  • PipPipPipPipPipPipPip
  • 6,885 posts
  • Gender:Male

Posted 24 June 2016 - 10:40 PM

As far as I can tell Red Racer is the only shop up here so I'm used to that sort of distance to mess about. Am I missing any?
Captain's log: We are enroute to some planet whose name I cannot pronounce to do something really complicated that I don't understand.

#27 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 24 June 2016 - 11:29 PM

It would be no more if not quicker to get to my house from Bellbird Park
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#28 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 26 June 2016 - 04:17 PM

Some more progress was done over the weekend, the new section still needs more fixing down which will give a much better shape into the banked corner. This banked corner is where the 3 wide section will also finish. Only one more corner to go then onto the 3 wide back straight.

Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image
Posted Image


Cheers John
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#29 miveson

    Raid

  • Members
  • PipPipPipPip
  • 2,911 posts
  • Gender:Not Telling

Posted 26 June 2016 - 05:35 PM

That banked corner looks fantastic. The MDF looks damn thick, 18mm? Can I see grooves that you've cut in to the underside of the track to help with the banking?

Curious as to what tool you used for that as I need to do some humps on MDF soon (that doesn't sound right but anyways)

#30 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 26 June 2016 - 06:19 PM

View Postmiveson, on 26 June 2016 - 05:35 PM, said:

That banked corner looks fantastic. The MDF looks damn thick, 18mm? Can I see grooves that you've cut in to the underside of the track to help with the banking?

Curious as to what tool you used for that as I need to do some humps on MDF soon (that doesn't sound right but anyways)

Thank you. Yes you are correct i had to groove the underside as it is 19mm that i had leftover from cutting up the old track i just flipped the pieces over so underneath the banked corner now there is still grass and some slots from the old track in between the grooves i routed to help the flex. It would have been easier to use 12mm and not groove but as i still had 3 large pieces of the old track sitting here so i may aswell save some money and use that. I used a 20mm straight bit for the grooving and i just done them by hand without using a guide. I will take some shots for my next update

Cheers John

Edited by Johnsxr8, 26 June 2016 - 06:20 PM.

Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#31 tonka500

    Kart Driver

  • Members
  • PipPip
  • 134 posts
  • Gender:Male
  • Location:South Coast NSW

Posted 27 June 2016 - 07:30 AM

That banked corner onto the straight looks so cool.

Nice work.

#32 DRMF1

    Kart Driver

  • Members
  • PipPip
  • 97 posts
  • Gender:Male
  • Location:Brisbane

Posted 29 June 2016 - 07:36 PM

Damn, I gotta get a bigger shed. <_<

#33 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 02 July 2016 - 09:03 AM

View Posttonka500, on 27 June 2016 - 07:30 AM, said:

That banked corner onto the straight looks so cool.

Nice work.

View PostDRMF1, on 29 June 2016 - 07:36 PM, said:

Damn, I gotta get a bigger shed. <_<

Thanks Guys hope to get some more work done this weekend so hopefully i will have a new update in the next couple of days

Cheers John
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#34 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 02 July 2016 - 06:14 PM

Got to add on another corner today i ran out of the old 19mm so back to 12mm which is easier to work with anyway, i still have to set the banking entering the corner but i will get around to that tomorrow or Monday, then once that is done i can do the back straight and then work my way into the more techincal section in the middle.

Here is a shot of the underside of the 19mm piece that i grooved out underneath to help with banking
Posted Image



And where i am at today
Posted Image
Posted Image
Posted Image
Posted Image
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#35 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 03 July 2016 - 09:21 PM

Managed to sneek in a little bit more this arvo after a family outing and got a couple more supports in plus routed and fit the first section of the back straight

Posted Image
Posted Image
Posted Image
Posted Image
Posted Image

Cheers John
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#36 miveson

    Raid

  • Members
  • PipPipPipPip
  • 2,911 posts
  • Gender:Not Telling

Posted 04 July 2016 - 07:17 AM

This track is looking fantastic - keep the pictures and progress updates coming along.

#37 Capri-corn7

    Metrobro Driver

  • Members
  • PipPipPip
  • 1,311 posts
  • Gender:Male
  • Location:Napier

Posted 04 July 2016 - 08:44 AM

Yep you have to steal that time where you can... enjoying this build - Thanks for the detailed pics too.
They are only toys .... until you pull the trigger.

#38 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 04 July 2016 - 09:04 AM

Thanks guys, my wife and kids are going away this weekend so most of my weekend especially Saturday will be spent in the shed so i hope to have a good update next weekend
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#39 Johnsxr8

    Digital Racer

  • Members
  • PipPip
  • 517 posts
  • Gender:Male
  • Location:Burpengary, Brisbane

Posted 08 July 2016 - 07:32 PM

More progress was done today with the back straight and the longest straight now all routed, it will get shortened a little bit to accommodate the corner coming onto the straight. Still need alot more supports fitted but will do them during the week. Now to begin the technical middle section over the weekend.

Posted Image
Posted Image
Posted Image
Posted Image

Cheers John
Check out North Brisbane Slotcar Racing: http://northbrisslots.forumotion.com

#40 ZeGas

    ZeGas

  • Members
  • PipPipPip
  • 1,155 posts
  • Gender:Male
  • Location:Mundoolun, QLD

Posted 08 July 2016 - 07:38 PM

There seems to be a lot of elevation at the back John will we be able to see the cars
Cheers Grant
Posted Image.......................................................Posted Image
Home Track..........Corvette C1 Build..........McLaren M1A Build..........Maserati 300S Build..........Allard J2 Build..........50's Diner..........Iso Griffo A3C

3D Printed Adjustable Chassis..........3D Print Projects

If life gives you lemons, take them, free s#!t is cool.
